PowMr Hybrid Solar Inverter 4.2KW/6.2KW MPPT 24V-48V To 220Vac
PowMr Hybrid Solar Inverter 4.2KW/6.2KW MPPT 24V-48V To 220Vac
Couldn't load pickup availability
Power your home with flexible, intelligent energy management using the PowMr hybrid solar inverter, scalable from 4.2kW to 6.2kW and converting 24V–48V DC to 220Vac.
- You get MPPT 120A with up to 6200W (4.2kW) or 8000W (6.2kW) PV input, nominal PV voltages of 240Vdc or 360Vdc, and a 60–450Vdc MPPT range.
- In line mode or inverter mode, you receive a Pure Sine Wave 230Vac output at 50/60Hz with fast transfers (10 ms UPS, 20 ms for loads).
- You choose from three charging modes (Only Solar, Solar First, Solar & Utility) and three output modes (SUB, SBU, MKS); adjust charging current and input range via the LCD.
- The unit auto-restarts after AC recovery and provides protection against overload, over-temperature, and short circuits; compact 45×36×15 cm, 8 kg, CE EU LVD certified.
INVERTER MODEL |
POW-HVM4.2K-24V-E |
POW-HVM6.2K-48V-E |
Line Mode Specifications | ||
Input Voltage Waveform |
Pure Sine Wave(Utility or Generator) |
|
Nominal Input Voltage |
230Vac |
|
Max AC Input Voltage |
300Vac |
|
Efficiency(Line Mode) |
>95%( Rated R load,battery full charged) |
|
Transfer Time |
10ms typical(UPS);20ms typical(Appliances) |
|
Inverter Mode Specifications | ||
Rated Output Power |
4.2KW |
6.2KW |
Output Voltage Waveform |
Pure Sine Wave |
|
Output Voltage Regulation |
230Vac±5% |
|
Output Frequency |
50HZ |
|
Peak Efficiency |
93% |
|
Overload Protection |
3s@≥150% load;5s@101%~150% load |
|
Surge Capacity |
2* rated power for 5 seconds |
|
Nominal DC Input Voltage |
24Vdc |
48Vdc |
Cold Start Voltage |
23.0Vdc |
46.0Vdc |
No Load Power Consumption |
25W |
50W |
Charge Mode Specifications | ||
Charging Algorithm |
3-Step |
|
AC Charging Current (Max) |
100A |
100A |
Max. PV Array Power |
6200W |
8000W |
Nominal PV Voltage |
240Vdc |
360Vdc |
PV Array MPPT Voltage Range |
60Vdc~450Vdc |
|
Max. PV Array Open Circuit Voltage |
500Vdc |
|
Max Charging Current(AC charger plus solar charger) |
120A |
120A |
Grid-Tie Operation | ||
Nominal Output Voltage |
220/230/240VAC |
|
Feed-in Grid Voltage Range |
195-253VAC |
|
Feed-in Grid Frequency Range |
49-51±1Hz/59-61±1Hz |
|
Nominal Output Current |
18.2A |
26.9A |
Maximum Conversion Efficiency(DC/AC) |
97% |
|
Two Load Output Power | ||
Full Load |
4200W |
6200W |
Maximum Main Load |
4200W |
6200W |
Maximum Second Load Range |
840W~2940W |
1240W~4340W |
Main Load Cut Off Voltage |
26VDC |
52VDC |
Main Load Return Voltage |
27VDC |
54VDC |
